LX type new electric single-beam suspension crane
LX type electric single-beam suspension crane is designed and manufactured in strict accordance with national standards, lifting weight of 0.5t-10, span of 3-16m, working level of A3-A4, working environment temperature of -20 – +40℃, prohibited in flammable, explosive and corrosive media environment. For general workshop and warehouse loading and unloading and handling goods. The operation forms are ground operation, remote control, ground operation and remote control.
Product characteristics
1. Configure emergency stop switch, short circuit protection, voltage loss protection, phase sequence protection and other functions;
2. Lifting, car, car three independent control, can run alone or at the same time;
3. All connections are quick plug type heavy aviation plug and socket, sealed well, firmly inserted, easy to maintain;
4. The plug connection part is protected by plastic sleeve insulation;
5. The car limit device can adjust the position according to actual use;
6. The mobile power supply system adopts PVC flat cable dedicated to the crane, and the pressure rating reaches 450/750V;
7. The trolley mobile power supply system adopts built-in cable block, galvanized track and flat cable.
8. Overload limiter;
9. Upper and lower limit switch;

Applicable occasion
It is mostly used for occasions with small weight and low frequency.
